Modified stainless steel tubes
We perform not only round tube, square tube but also sale of the modified tube too.
To correspond to user's variegated demand and use condition, it establishes the production system.
Flat square tube
Flat square tube SUS304 <HL>
: HL| Size(mm) a × b |
Length (mm)＼W.t (mm) | 1.2 | 1.5 |
|---|---|---|---|
| 6×12 | 4,000 | ● | |
| 6×25 | 4,000 | ● | ● |
| 6×30 | 4,000 | ● | ● |
| 6×40 | 4,000 | ● | ● |
| 6×50 | 4,000 | ● | ● |
| 6×65 | 4,000 | ● | |
| 6×75 | 4,000 | ● | |
| 6×100 | 4,000 | ● | |
| 9×25 | 4,000 | ● | |
| 9×30 | 4,000 | ● | |
| 9×40 | 4,000 | ● | |
| 9×50 | 4,000 | ● | ● |
| 9×65 | 4,000 | ● | ● |
| 9×75 | 4,000 | ● | |
| 9×100 | 4,000 | ● | |
| 12×50 | 4,000 | ● | ● |
| 12×65 | 4,000 | ● | |
| 12×75 | 4,000 | ● | |
| 12×100 | 4,000 | ● |
Dimensional Tolerance
| Outside diameter | ±0.5mm |
|---|---|
| Wall thickness | ±0.2mm |
Square channel tube
Square channel tube SUS304 <HL,#400>
| Size(mm) a × b × c × d |
Length (mm)＼W.t (mm) | 1.5 | 2.0 | ||
|---|---|---|---|---|---|
| HL | #400 | HL | #400 | ||
| 50×25×20×20 | 5,000 | ● | ● | ||
| 60×30×25×20 | 5,000 | ● | ● | ||
| 80×40×30×25 | 5,000 | ● | ● | ||
| 100×50×30×30 | 5,000 | ● | ● | ||
Channel tube
Channel tube SUS304 <HL,#400>
| Size(mm) a × b × c |
Length (mm)＼W.t (mm) | 1.5 | 2.0 | ||
|---|---|---|---|---|---|
| HL | #400 | HL | #400 | ||
| 34×15×20 | 5,000 | ● | ● | ||
| 38×20×20 | 5,000 | ● | ● | ||
| 42.7×20×20 | 5,000 | ● | ● | ||
| 48.6×20×20 | 5,000 | ● | ● | ||
| 50×20×20 | 5,000 | ● | ● | ||
| 60.5×20×20 | 5,000 | ● | ● | ||
| 76.3×25×30 | 5,000 | ● | ● | ||
| 89.1×25×30 | 5,000 | ● | ● | ||
| 101.6×30×40 | 5,000 | ● | ● | ||
Round shell tube
Round shell tube SUS304 <HL>
: HL| Size(mm) a × b |
Length (mm)＼W.t (mm) | 1.5 |
|---|---|---|
| 62×40 | 6,000 | ● |
Oval tube
Oval tube A-type SUS304 <HL,#400>
| Size(mm) a × b |
Length (mm)＼W.t (mm) | 1.2 | 1.5 | 2.0 | 3.0 | ||
|---|---|---|---|---|---|---|---|
| HL | #400 | HL | #400 | HL | HL | ||
| 28×16 | 5,000 | ● | ● | ||||
| 40×20 | 5,000 | ● | ● | ||||
| 50×20 | 5,000 | ● | ● | ||||
| 60×30 | 5,000 | ● | ● | ||||
| 71×23 | 5,000 | ● | ● | ● | ● | ||
| 84×28 | 5,000 | ● | |||||
| 120×45 | 5,000 | ● | |||||
| 220×100 | 6,000 | ● | |||||
Oval tube B-type SUS304 <HL,#400>
: HL
: #400| Size(mm) a × b |
Length (mm)＼W.t (mm) | 1.5 | |
|---|---|---|---|
| HL | #400 | ||
| 35×19 | 5,000 | ● | ● |
Oval tube C-type SUS304 <HL,#400>
| Size(mm) a × b |
Length (mm)＼W.t (mm) | 1.2 | 1.5 | 2.0 | |
|---|---|---|---|---|---|
| HL | HL | #400 | HL | ||
| 37×14 | 5,000 | ● | |||
| 40×15 | 5,000 | ● | ● | ||
| 46×20 | 5,000 | ● | ● | ● | |
| 80×25 | 5,000 | ● | ● | ||
| 100×35 | 5,000 | ● | |||
Semicircular tube
Semicircular tube SUS304 <HL,#400>
| Size(mm) a × b |
Length (mm)＼W.t (mm) | 1.5 | 2.0 |
|---|---|---|---|
| HL | HL | ||
| 60×30 | 5,000 | ● | ● |
| 80×40 | 5,000 | ● |
