Square for Ornamental and structural applications

Square for Ornamental and structural applications
(Square) SUS304 <Not polished,HL,#400,#800>

(Unit : mm)

Size	L	W.t	0.8			1.0			1.2			1.5			2.0			3.0
Size	L	Finish	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0
7×7	4,000						●	●
9×9	3,000			●	●		●	●
9×9	4,000			●	●		●	●
10×10	4,000						●	●		●	●
12×12	4,000					●	●	●	●	●	●
13×13	4,000					●	●	●	●	●	●
14×14	4,000					●	●	●	●	●	●	●	●	●
16×16	5,000					●	●	●	●	●	●	●	●	●
16×16	6,000											●	●	●
19×19	5,000					●	●	●	●	●	●	●	●	●	●	●	●
19×19	6,000											●	●	●
20×20	5,000								●	●	●	●	●	●
21×21	5,000					●	●	●	●	●	●	●	●	●
22×22	5,000					●	●	●	●	●	●	●	●	●
24×24	5,000					●	●	●	●	●	●	●	●	●
25×25	5,000								●	●	●	●	●	●
25×25	6,000											●	●	●
25.4×25.4	5,000								●	●	●	●	●	●
28.6×28.6	5,000					●	●	●	●	●	●	●	●	●
30×30	5,000								●	●	●	●	●	●	●	●	●
30×30	6,000											●	●
32×32	5,000								●	●	●	●	●	●	●	●	●
32×32	6,000											●	●	●
35×35	5,000								●	●	●	●	●	●
38.5×38.5	5,000								●	●	●	●	●	●	●	●	●
40×40	5,000											●	●	●	●	●	●
40×40	6,000											●	●	●
41×41	5,000								●	●	●	●	●	●	●	●	●
41×41	6,000											●	●	●
46×46	5,000											●	●	●	●	●	●
50×50	5,000											●	●	●	●	●	●	●	●	●
50×50	6,000											●	●	●	●	●	●	●	●	●
60×60	5,000											●	●	●	●	●	●	●	●	●
60×60	6,000											●	●	●	●	●	●
75×75	5,000														●	●	●	●	●	●
75×75	6,000														●	●	●
100×100	5,000														●	●	●	●	●	●
100×100	6,000														●	●	●

Square for ornamental and structural applications
(Rectangular) SUS304 <Not polished,HL,#400,#800>

(Unit : mm)

Size	L	W.t	1.0			1.2			1.5			2.0			3.0
Size	L	Finish	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0	N.P	H L	# 4 0 0
19×10	4,000		●	●	●	●	●	●
22×12	5,000		●	●	●	●	●	●	●	●	●
24×14	5,000		●	●	●	●	●	●	●	●	●	●	●
25×12	5,000					●	●	●	●	●	●
32×16	5,000		●	●	●	●	●	●	●	●	●
32×16	6,000								●	●	●
30×20	5,000					●	●	●	●	●	●
30×20	6,000								●	●	●
30×25	5,000					●	●	●	●	●	●
40×18	5,000		●	●	●	●	●	●	●	●	●
40×20	5,000					●	●	●	●	●	●	●	●	●
40×20	6,000								●	●	●
40×25	5,000					●	●	●	●	●	●	●	●	●
40×25	6,000								●	●	●
50×20	5,000					●	●	●	●	●	●	●	●	●
50×25	5,000								●	●	●	●	●	●
50×25	6,000								●	●	●
51×26	5,000					●	●	●	●	●	●	●	●	●
51×26	6,000								●	●	●
50×30	5,000								●	●	●	●	●	●
50×30	6,000								●	●	●
65×18	5,000					●	●	●	●	●	●
60×25	5,000								●	●	●	●	●	●
60×30	5,000								●	●	●	●	●	●
60×30	6,000								●	●	●	●	●	●
61×32	5,000								●	●	●	●	●	●
61×32	6,000								●	●	●
70×25	5,000								●	●	●	●	●	●
60×40	5,000								●	●	●	●	●	●	●
70×30	5,000								●	●	●	●	●	●
75×25	5,000								●			●	●
75×45	5,000								●	●	●	●	●	●	●	●	●
75×45	6,000								●	●	●	●	●	●
80×40	5,000								●	●	●	●	●	●	●	●	●
80×40	6,000								●	●	●	●	●	●
90×30	5,000								●	●	●	●	●	●	●	●
90×30	6,000								●	●	●
90×50	5,000								●	●		●	●	●	●	●	●
100×40	5,000											●	●	●	●	●	●
100×50	5,000											●	●	●	●	●	●
100×50	6,000											●	●	●	●	●	●
120×60	5,000											●	●	●	●	●	●
150×50	5,000											●	●	●	●	●	●
125×75	5,000											●	●	●	●	●

Square for ornamental and structural applications
(Rectangular) SUS430 <HL>

Size	Length ＼ Wall thickness	1.0	1.2
32×16	5,000	●	●

Dimensional Tolerance

Specified item and dimension		Tolerance
Side Length (L mm)	L<30mm	±0.20mm
	30≤L<50mm	±0.25mm
	L≥50mm	±0.5%
Wall thickness(W.t mm)		±10%
Length(L mm)		+ Not specifeid,-0
Angle between neighboring flat surfaces		90ﾟ ±1.5ﾟ
Straightness	over all length	≤ 0.3%
Dimension of each section (s)	W.t < 2.0mm	1W.t or less
Dimension of each section (s)	W.t ≥ 2.0mm	1.25W.t or less

Examples

gate

Gate

Fence

Fence
