Model:PCH
This is cutting machine of the work rotary type.
This is machine which develops to improve production capacity, and a cutting machine of two head type.
| Item | Processing method | Tool | Process | Processing form | |
|---|---|---|---|---|---|
| Both side chamfering | One side chamfering | ||||
| Tube Cutting | Work Rotated | Byte or Chip | ○ | ○ |  |
Standard Arrangement
| Item / Model No. | PCP-38N2 | PCP-65N2 | ||
|---|---|---|---|---|
| Cutting Size | Tube O.D | 10mm～38mm | 10mm～60.5mm | |
| Tube Thickness | t 5mm Max. | |||
| Length | Standard | 25～350mm | 25～350mm | |
| Option | 1,500mm Max | |||
| Spindle R.P.M | 600～1,000r.p.m. Inverter |
270～800r.p.m. Inverter |
||
| Moter | Main Spindle | 2.2kwx2 | 3.7kwx2 | |
| Feeder | 0.4kw x 2(Inverter) | |||
| Dimensions | Main Body | 1,500mm(overall length) x1,290mm(width) | ||
| Tube Supply | 7,040mm(overall length) x 2,020mm(width) | |||
| Weight | Main Body | 1,100kgs | 1,200kgs | |
| Tube Supply | 350kgs | |||
| Air Pressure | 0.5Mpa | |||
| Production Speed | 4sec/1head : Mild Steel Tube 22.2mm dia. x t1.2 x 100mm L | |||
- Advice is given about the adjustment of voltage.
- Specifications are subject to change without notice.
