Model:PCG
This is cutting machine of the work rotary type.
This is cutting machine which developed as the material cutting for the bearing and many can cut it at the same time.
| Item |
Processing method |
Tool |
Process |
Processing form |
| Both side chamfering |
One side chamfering |
| Tube Cutting |
Work Rotated |
Byte |
× |
× |
 |
PCPG Series(Standard Arrangement)
| Item ＼ Model |
PCPG-83N3S |
| Cutting Size |
Tube O.D |
10mm～83mm |
| Tube Thickness |
Max t8mm |
| Length |
180mm (inside width of tool post) |
| Spindle R.P.M |
250～1,000r.p.m.
Inverter |
| Motors |
Main Spindle |
5.5kw 6P (Inverter) |
| Hydraulic |
0.75kw 4P |
| Feeder |
0.75kw 4P (Inverter) |
| Coolant |
2.2kw 4P x 1 |
| Slide Drive |
Servo Motor (0.6kw) |
| Dimensions |
Main Body |
9,500mm(over length) x 2,230mm(width) |
| Weight |
Main Body |
2,000kgs |
| Tube Supply |
350kgs |
| Air |
0.5Mpa |
- Advice is given about adjustment of voltage Specifications are subject to change without notice
