Model:PC
This is cutting machine of the work rotary type.
A standard cutting machine, and the cutting method to be byte cutting, and disc cutting etc.
| Item | Processing method | Tool | Process | Processing form | |
|---|---|---|---|---|---|
| Both side chamfering | One side chamfering | ||||
| Tube Cutting | Work Rotated | Byte or Chip | ○ | × |  |
| × | ○ |  |
|||
PCP-N2 Series(Standard Arrangement)
| Item ＼ Model | PCP－38N2 | PCP-65N2 | PCP-83N2 | ||
|---|---|---|---|---|---|
| Cutting Size | Tube O.D | 10mm～35mm | 10mm～60.5mm | 20mm～80mm | |
| Tube Thickness | t 5mm Max. | ||||
| Length | Standard | 25～350mm | 25～350mm | 25～350mm | |
| Option | 1,500mm Max | ||||
| Spindle R.P.M | 600～1,000r.p.m. Inverter |
270～800r.p.m. Inverter |
155～455r.p.m. Inverter |
||
| Moter | Main Spindle | 2.2kw | 3.7kw | ||
| Feeder | 0.4kw x 1(Inverter) | ||||
| Dimensions | Main Body | 1,500mm(overall length) x1,030mm(width) | |||
| Tube Supply | 8,300mm(overall length) x 1,300mm(width) | ||||
| Weight | Main Body | 750kgs | 800kgs | 850kgs | |
| Tube Supply | 200kgs | ||||
| Air Pressure | 0.5Mpa | ||||
| Production Speed | 4second : Mild Steel Tube 22.2mm dia. x t1.2 x 100mm L | ||||
- Advice is given about the adjustment of voltage.
- Specifications are subject to change without notice.
Large Type
| Item ＼ Model | PCP-140N2 | PCP-180N2 | PCP-280N2 | ||
|---|---|---|---|---|---|
| Cutting Size | Tube O.D | 60mm～140mm | 100mm～180mm | 100mm～280mm | |
| Tube Thickness | 10mm Max | 15mm Max | |||
| Length | Standard | 25～350mm | 25～350mm | 25～350mm | |
| Option | 1,500mm Max | - | |||
| Spindle R.P.M | 100～400r.p.m. Variable Speed Gear |
80～300r.p.m. Variable Speed Gear |
50～200r.p.m. Variable Speed Gear |
||
| Moter | Main Spindle | 5.5kw | 7.5kw | 22kw | |
| Feeder | 0.75kw | 1.5kw | |||
| Hydraulic | - | 5.5kw | |||
| Dimensions | Main Body | 2,200mm (overall length) x 1,200mm (width) | Adjustment | ||
| Tube Supply | Adjustment | ||||
| Weight | Main Body | 1,500kgs | 2,500kgs | 10,000kgs | |
| Tube Supply | 700kgs | 4,500kgs | |||
| Pressure | Air | 0.5Mpa | |||
| Hydraulic | - | 3Mpa | |||
| Production Speed (Mild steel) |
φ114.3mm x t4.5 20 sec/pcs |
φ165.2mm x t5.0 25 sec/pcs |
φ267.4mm x t6.6 35 sec/pcs |
||
- Advice is given about the adjustment of voltage.
- Specifications are subject to change without notice.
